Heating function |
|
heating power (kW) | 0.9 |
heated zone (mm) | Ø 155 |
max. hot plates temperature (°C) | approx. 550 |
min. time to boiling point 1 l H2O* (min) | approx. 15 |
temperature sensor connector | yes, Pt 1000 |
setting accuracy with temperature sensor (°C) | 1 |
controlling accuracy with temperature sensor** (°C) | ± 2 ... 5 |
hot plate material | glass ceramic |
hot plates area (mm) | 235 x 235 |
digital set/actual temperature display | yes |
Stirring function |
|
max. rpm (min-1) | 100 - 1100 |
setting accuracy rpm (min-1) | 10 |
max. stirring volume (l H2O) | 10 |
digital set/actual rpm display | yes |
General data |
|
dimensions (L x W x H in mm) | 370 x 240 x 85 |
weight (kg) | approx. 3.8 |
max. load (kg) | 25 |
admissible ambient temperature (°C) | 10 - 40 |
admissible air humidity (%) | 85 |
protection type | IP 20 |
protection class | 1 |
housing material | die-cast |
cable connector | fixed cable |
mains connection (V/Hz) | 230 V, 50/60 or 115 V, 50/60 |
Order No. 230 V | 28 541 6373 |
Order No. 115 V*** | 28 541 6279 |
